Differential pressure measurement in pressurized tanks, differential pressure measurement for filter monitoring
Level Sensors, Modular Platform, Pressure Sensors | Food, Beverage and Dairy
Differential pressure measurement in pressurized tanks, differential pressure measurement for filter monitoring.
- Parallel display of differential pressure and head or system pressure in the display and two mA output interfaces
- Pressure sensor and electronics using digital signaling to avoid negative impact of temperature changes
- Simple and reliable remote wire cable avoid frequent recalibration
- Improved temperature compensation reduces errors in process temperature changes
- Graphical user interface with intuitive settings
- Integrated tank linearization and density compensation in the sensor
- Due to the modular design, components of the sensor can be replaced on site
- Optionally one or two remote pressure sensors
- Predefined and customized tank geometries and product properties adjustable
- 2x standard 4 … 20mA interfaces incl. HART 7.0 communication
- Measuring range from -1 … 35 bar
- Total length between two pressure sensors up to 30m
Application examples:
- Level measurement in pressurized vessels and tanks
- Measurement in breweries lauter tun vessels
- Measurement in sterile tanks in dairy
